9508H One-Component Heat-Curing Type TC >8.0 W/M·K Excellent Workability Low Static / Transient Stress On Substrates

Name: 9508H OneComponent HeatCuring Type TC gt80 WMK Excellent Workability Low Static Transient Stress On Substrates
Brand: HUITIAN
Price: 1 USD

Quality 9508H One-Component Heat-Curing Type TC >8.0 W/M·K Excellent Workability Low Static / Transient Stress On Substrates for sale

Brand Name : HUITIAN

Model Number : 9508H

Certification : RoHS

Place of Origin : CHINA

MOQ : 180 kg

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 4000KG/Month

Delivery Time : 5-8 days

Packaging Details : 30cc/tube; 300cc/cartridge

Physical Form : Paste

Color : Light green

Density : 3.3 g/cm³

Flow rate : 120 g/min

Volume resistivity : 1.0*10^12 Ω∙cm

Dielectric strength : ＞5.0 KV/mm

Thermal Conductivity : 8 W/(m•K)

Contact Now

9508H TDS-EN.pdf

9508H is one-component Heat-curing type; TC >8.0 W/M·K; Excellent workability and Low static/transient stress on substrates

Product Description

Light green gel
One-component heat-curing type
Silicone thermal conductive composite

Product Features:

High thermal conductivity ＞8W/m∙K
Excellent workability
Low static/transient stress on substrates
High reliability under various conditions
9508H can be stored for a long time at low temperatures, has a long operating time at room temperature and can be cured quickly at high temperatures

Technical Parameters

Standard	Property	Unit	Result
一	Component	-	One
Visual	Color	-	Light green
一	Flow rate	g/min	120
ASTM D792	Density	g/mL	3.3
一	Bond line thickness	mm	0.28
-	Operational time @25℃	d	>60
-	Curing time @150℃	min	30
ASTM D5470	Thermal conductivity	W/(m·K)	>8.0
ISO22007-2	Thermal conductivity	W/(m·K)	>10.0
ASTM D5470	Thermal Impedance	℃·cm²/W	0.38
ASTM D257	Volume resistivity	Ω·cm	>1.0x10¹²
ASTM D149	Dielectric strength	kV/mm	>5
UL94	Flame retardant grade	-	V0
-	Working temperature	℃	-40─150

Main Applications:

Automotive electronic equipment
Mobile electronics
Communication base station
Graphics card
Microprocessors and chips

Packing:

30cc/tube; 300cc/tube

Storage:

Store below 35°C in a cool and dry place.

Shelf life is 6 months.
